Products Gaskets Metallic Gaskets > Kammprofile Gaskets

Kammprofile Gaskets

942A Kammprofile Gaskets 942A

Manufactured from solid metal, CANFLEX® Kammprofile gaskets combine all of the desirable qualities of a solid metal gasket with the added advantages of a reduced area of contact, resulting in lower stress values required to achieve a seal. As a standard, flexible graphite is bonded to each face due to its superior sealing characteristics. Other metallurgies and soft gasket sealing materials are available in order to accommodate specific chemical and temperature service requirements.

Style 942A Kammprofile Gasket

942A is manufactured from solid metal, Kammprofile gaskets exhibit all the desirable qualities of a solid metal gasket with the added advantages of a reduced area of contact thereby reducing the bolt stress required to make a seal. Grafoil tape is added to the sealing surface for improved sealability. Because of their ability to seal on less than perfect flange faces, Cammprofile gaskets are often chosen as a replacement to traditional double-jacketed heat exchanger gaskets.​

942 AR2 Cammprofile Gaskets 942AR2

Style 942 AR2 Kammprofile Gasket

942 AR2 Kammprofile gasket designed to accommodate standard ASME flanges in applications up to 2500#. Floating centering ring allows for expansion and contraction in applications where thermal cycling is prevalent.

Download Brochure
